Description

T SUB AX12B

EVERYONE LOVES BASS !!

  • 12″ Active sub
  • Dual layer driver
  • 2.0″ voice coil
  • 500 W Continuous
  • 1000 W Peak

EVERYONE LOVES BASS !

That is exactly why we have created the T-Sub-AX series of active subwoofers.

The internal Class D amplifier delivers huge output power into the custom Wharfedale Pro LF driver to produce extreme subs and low end pressure into any system. Built for big bass, the plywood constructed cabinet is rock solid and is protected in durable black paint.

You’ll not only ‘feel’ a T-SUB-AX, but you will also see it! A new illuminated WP logo badge subtly glows and adds to the overall on-stage “power” of the new T-Sub.

T-Sub-AX models are designed to be the perfect companion for a Typhon or a Titan active loudspeaker.

Hold on to your socks! T-Sub-AX is going to blow them off!

PERFECT PAIRING

T-Sub-AX models have been designed to be the perfect partner for Wharfedale Pro plastic active loudspeakers.

Used with a Tourus, a Titan or our flagship Typhon models, a T-Sub-AX completes the system – bringing new levels of bass to the setup.


PROTECT THE BASS

Protective optional soft covers are available for all T-Sub-AX Active Subwoofers.

With easy access to both carry handles and a soft protective padding, the T-Sub soft covers are simple to put on and simple to remove – making setup and breakdown easy.

SPECIFICATIONS



Model Name T-Sub-AX12B
System Type Active 12″ Subwoofer
Frequency Response (+/-3 dB) 50 Hz-200 Hz
Frequency Response (+/-10 dB) 45 Hz-250 Hz
Sensitivity @ 1 w / 1 meter 97 dB
Maximum SPL (peak @ 1 meter) Half space. 130 dB
Low Frequency Transducer
Size (mm / inches) 305 mm / 12”
Coil Size (mm / inches) Dual layer 51.3 mm / 2″
Impedance 4 Ω
Amplifier
Low-Frequency Power Amplifier (Class D) 500 W Continuous / 1000 W Peak
Crossover Frequency LPF 80-200 Hz (adjustable)
Controls
Amplifier Protection Yes
Power On Protection Power switch on / off mute
Thermal Protection Amplifier shutdown, auto reset
Driver Protection Yes
DC Protection Yes
Short Protection Yes
Limiter Indicator Red LED
Input type Balanced
Input Connector 2 x socket XLR
Input Impedance 47 kΩ Balanced
Maximum Input Level 5 V
Input Sensitivity -10 dBu
Link Output Connector 2 x pin XLR
Polarity Switch Selection 0° / 180°
AC Power details
Power Supply SMPS
AC Power Options 100 V-120 V and 200 V-240 V
Power Indicator Green (back) / Blue logo (front)
Enclosure
Enclosure Material 15 mm Plywood
Colour Black
Paint Tough-Tone
Grille 1.5 mm steel
Pole Mount (Top) 35 mm
Dimensions (Unpacked)(mm / inches)
Height 378 mm / 14.9″
Width 493 mm / 19.4″
Depth 468 mm / 18.4″
Dimensions (packed)(mm / inches)
Height 475 mm / 18.7″
Width 563 mm / 22.2″
Depth 538 mm / 21.2″
Weight
Net Weight (kg / lbs) 21.0  kg / 46.2  lbs
Gross Weight (kg / lbs) 25.5 kg / 56.1 lbs
