Electro-Voice ELX200-10P

Sale price$1,745.00


The ELX200-10P has integrated QuickSmartDSP and high-efficiency Class-D power amplifiers (up to 1200 W) that deliver up to 130 dB SPL using EV-designed and engineered transducers (10-inch EVS-10M woofer and 1-inch titanium compression driver). With four presets (Music, Live, Speech, and Club), sub/top system-match crossovers, three-band EQ, five user-programmable presets (Settings for Store and Recall), visual monitoring of limiter status, input level control and meters, and master volume control for optimal gain structure, powered full-range models make setup simple.

With their lightweight and long-lasting polypropylene enclosures, three M10 threaded mounting points, and the tried-and-true ZLX handle design for simple lifting, powered ELX200 models are ideal for both portable and installed applications.

Using Bluetooth Low Energy (BTLE) technology, the new QuickSmart Mobile wireless control and monitoring application makes it possible to control, configure, and monitor up to six powered ELX200 loudspeakers simultaneously. Control your system while standing in front of your speakers rather than behind them, and get alerts when your system is being overdriven. Only a few nations offer Bluetooth.

  • EV QuickSmart Mobile application: quickly and wirelessly configure, control and monitor up to six ELX200 loudspeakers simultaneously, and receive immediate notification during critical performance conditions. Bluetooth is available in select countries.
  • QuickSmartDSP features best-in-class processing. Easy setup via four presets, sub/top system-match, three-band EQ, five user-programmable presets, visual monitoring of limiter status, input level control and meters, and master volume control to optimize gain structure, all via LCD.
  • High-efficiency 1200 W Class-D power amplifier delivers up to 130 dB peak SPL utilizing transducers designed and engineered by EV.
  • EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
  • Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX two-handle design for easy lifting.
Coverage (H x V) 90˚ x 60˚
Power rating 1200 W
LF transducer EVS-10M 254 mm (10 in)
HF transducer DH-1L 1-inch titanium compression driver
Crossover frequency 1800 Hz
Connectors (1) Stereo RCA Input, (2) XLR/TRS combo jack, and (1) XLR
Enclosure Polypropylene
Grille 18 AWG steel with powdercoat
Suspension (3) M10 suspension points
Color Black or White
Dimensions (H x W x D) 531 mm x 330 mm x 319 mm (21.0 in x 13.0 in x 12.6 in)
Net weight 13.5 kg (29.9 lb)
Shipping weight 15.6 kg (34.4 lb)
Power consumption 100 - 240 V~, 50 - 60 Hz, 1.2 ~ 0.6A³
