Wharfedale Pro Delta-AX15B Active Subwoofer

Wharfedale Pro
Price:
$979.00
Contact us for availability

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Description

  • 15″ active subwoofer
  • Low pass filter control
  • Hi Pass link outputs
  • 42 Hz – 200 Hz Frequency response
  • 180° phase switch
  • 4″ LF voice coil
  • 900 watts Continuous
  • 1800 watts Peak
  • 130 dB Max SPL @ 1m

    BIRCH PLYWOOD

    All Delta-AX models use premium Baltic birch plywood construction.

    Not only does this create a solid and durable cabinet, but it also contributes to the overall sound and character.

    Delta-AX is also covered in our most durable and hard wearing Rhino Rock paint finish. This ensures that a Delta-AX will always look as good as the day you unboxed it.

    ROUTED LOGO

    Delta-AX features a routed Wharfedale Pro logo.

    This fresh design helps to distinguish between the original Delta-A models and the updated Delta-AX models.

    It is also a logo to be proud of. A logo that lets your audience know that the sound of your even will be of the highest possible quality.



     Specifications:

    Model Name DELTA-AX15B
    System Type Active 15” Subwoofer
    Frequency Response (+/-3 dB) 42 Hz – 200 Hz
    Calculated Maximum SPL @1 m 130 dB
    Low Frequency Transducer –
    Size (mm / inches)    		 404 mm / 15″
    Coil Size (mm / inches) 101.6 mm / 4″
    Impedance 8 Ω
    Amplifiers
    Low-Frequency Power Amplifier RMS 900 w (Class D)
    High-Frequency Power Amplifier RMS NA
    Amplifier Protection Yes
    Power On Protection Power switch on/off mute
    Thermal Protection Amplifier Shut Down. Auto Reset
    Low Line Voltage Shut Down 80% Nominal Line Voltage
    Driver Protection Yes
    DC and Short Protection Yes
    Clip Limiter Turns on Appro x 900 w Output
    Limiter Indicator Red LED
    Power Indicator Green LED
    Connectors
    Input A – type Balanced
    Input Sensitivity Line:0 dBu
    Maximum Input Level 22 dBu
    Input Connector TRS jack and Female XLR
    Input Impedance Balanced:20 KΩ Unbalanced:10 KΩ
    Line Output Connector Male XLR Connector
    Impedance Balanced Balanced: 200 Ω Unbalanced:100 Ω
    Loop Gain 0 dB
    AC Power details – Power Supply High Efficiency SMPS
    AC Power Options AC100-120 V~ / 220-240 V~,50/60 HZ
    Power On Indicator Green LED
    Hardware – Rigging
    Enclosure Material and finish 15 mm Plywood
    Colour Options Black Rhino Paint
    Grille Material & Finish
    Unpacked dimensions – Height 471 mm / 18.54″
    Width (Front) 471 mm / 18.54″
    Width (Back) 471 mm / 18.54″
    Depth 600 mm / 23.62″
    Packed Dimensions – Height 556 mm / 21.89″
    Width (Front) 672 mm / 26.46″
    Width (Back) 672 mm / 26.46″
    Depth 543 mm / 21.38″
    Net Weight (kg / lbs) 33.1 kg / 72.82 lbs
    Gross Weight (kg / lbs) 36.7 kg / 80.74 lbs
